Key Specifications and Ratings
2.7 x 7.3 mmFast actingColor coded to response timeBox Quantity: 5PCS
Voltage Rating250VAC 60VDC
Current Rating125mA to 20A
Interrupt Rating50A AC 50A DC
Features and Application
- Subminiature (2.7 x 7.3mm) and cost-effective solution for printed circuit board component protection applications, eliminating the need for fuse holders by directly soldering onto the PCB.
- Fast acting and color-coded for easily indentification the fuse response time.
- Typically comes taped in an "ammo pack" of 4,000 pieces but can be reeled as well.
- NEW: Select products are available in pill boxes.
Dimensions and 3D view
![image](https://www.optifuse.com/doc-for-web/Drawing-Vector-Images/FXG.png)
Dimensions
Length0.11
Height0.29
Width0.11
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
![image](https://www.optifuse.com/doc-for-web/Drawing-Vector-Images/FXG.png)
Dimensions
Length0.11
Height0.29
Width0.11
UnitInch
