Key Specifications and Ratings
Manual Reset - Push to TripSurface mount with #10-32 studMarine rated
Voltage Rating32VDC
Current Rating10A to 60A
Interrupt Rating 2500A DC
Features and Application
- Mid-range amperage (up to 60A) to protect accessory applications in RVs, marine craft, emergency vehicles, and trucks. The interrupt rating meets ABYC requirements for DC branch circuit protection on large battery banks.
- Designed with a surface-mount installation style for secure and direct mounting onto equipment or vehicle surfaces.
- Waterproof and ignition-protected for use in marine engine compartments, meeting the rigorous SAE J1171 and ABYC standards.
- Conforms to the SAE J553 standard for circuit breaker performance.
Dimensions and 3D view
Dimensions
Length2.28
Height1.4
Width1.38
UnitInch
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length2.28
Height1.4
Width1.38
UnitInch
