Key Specifications and Ratings
Splash-proof design (IP 51)AC/DC ratingsSpace-saving compact size
Voltage Rating32VDC
Current Rating10A to 25A
Features and Application
- Designed for use with 6.3 x 32mm fuses, this space-saving in-line fuse holder is ideal when no surface is available to install the fuse using another mounting type. Commonly used as a part of a wire harness assembly in electronic equipment, appliances, and lighting circuits.
- Manufactured to withstand harsh environmental conditions with splashproof protection.
- Intended for use in DC circuits (up to 32VDC) and AC circuits (up to 250VAC), this holder accepts #14 to #18 wire leads (not provided).
Dimensions and 3D view
Dimensions
Length0.34
Height2.12
Width0.34
UnitInch
What is 3D CAD?
A 3D CAD (.STP) file ready to integrate into your project. Download and use it in your design software to streamline your workflow.
Custom solutions
Dimensions and 3D view
Custom solutions
Dimensions
Length0.34
Height2.12
Width0.34
UnitInch
What is 3D CAD?
A 3D CAD (.STP) file ready to integrate into your project. Download and use it in your design software to streamline your workflow.
